Sanden Compressors

Southern Sales & Services supply Sanden compressors for all your application requirements. If you only need to replace your worn out compressor or you would like to retrofit your current system, or even have a requirement for large quantities for production, then we cater for all your needs.

Replacement clutches, coils, cylinder heads and a variation of different port sized manifolds for the FLX7 series are available for repair and servicing your own compressor.

If there is a specific replacement part or model of compressor you wish us to source and supply, or you require information regarding the compressor selection that you have already made, then please do not hesitate to contact us by phone or by using the quick contact form at the bottom of the page.

Transport Refrigeration Piston Compressors developed to handle R404a refrigerant. Sanden R404a Compressors are capable of meeting all transport refrigeration requirements. The improved wobble-plate Compressor has improved lip seal, strengthened planet plate and pistons to work in a R404a environment. Sanden R404a range of Compressor has a “flex” type hose connections, suitable for almost any configuration.

Transport Refrigeration Piston Compressor Variants : SD5L & SD7L



Sanden compressors – Model SD5L09

Image of Sanden compressors - SD5L09 Image of Sanden compressors - SD5L09

Compressor Specification :

Bore ø35
Stroke 18.07 mm
Displacement Per Revolution 87 cc/rev
Number of Cylinders 5
Max. Allowable Continuous Speed 3000 RPM
Max. Downshift Speed 4000 RPM
Refrigerant R-404a
Oil (Mobil EAL Arctic 68 or Equiv) 0 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD5L11

Image of Sanden compressors - SD5L11 Image of Sanden compressors - SD5L11

Compressor Specification :

Bore ø35
Stroke 22.6 mm
Displacement Per Revolution 108 cc/rev
Number of Cylinders 5
Max. Allowable Continuous Speed 3000 RPM
Max. Downshift Speed 4000 RPM
Refrigerant R-404a
Oil (Mobil EAL Arctic 68 or Equiv) 0 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD5L14

Image of Sanden compressors - SD5L14 Image of Sanden compressors - SD5L14

Compressor Specification :

Bore ø35
Stroke 28.6 mm
Displacement Per Revolution 138 cc/rev
Number of Cylinders 5
Max. Allowable Continuous Speed 3000 RPM
Max. Downshift Speed 4000 RPM
Refrigerant R-404a
Oil (Mobil EAL Arctic 68 or Equiv) 0 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD7L13

Image of Sanden compressors - SD7L13 Image of Sanden compressor - SD7L13

Compressor Specification :

Bore ø29.3
Stroke 27.4 mm
Displacement Per Revolution 129.2 cc/rev
Number of Cylinders 7
Max. Allowable Continuous Speed 3000 RPM
Max. Downshift Speed 4000 RPM
Refrigerant R-404a
Oil (Mobil EAL Arctic 68 or Equiv) 0 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD7L15

Image of Sanden compressors - SD7L15 Image of Sanden compressors - SD7L15

Compressor Specification :

Bore ø29.3
Stroke 32.8 mm
Displacement Per Revolution 154.98 cc/rev
Number of Cylinders 7
Max. Allowable Continuous Speed 3000 RPM
Max. Downshift Speed 4000 RPM
Refrigerant R-404a
Oil (Mobil EAL Arctic 68 or Equiv) 0 cc
Rotation (Clutch View) Clockwise

Fixed Displacement Piston Compressors

The SD5 and SD7 series utilize a time-proven wobble-plate drive mechanism, which position all moving parts in the least possible package around the Compressor’s longitudinal axis for the greatest mechanical efficiency. The SD5 and SD7 series of Sanden Compressor combine durability and versatility that enable them to service a wide range of mobile air-conditioning applications. The SD5H and SD7H Compressor from Sanden is ready to handle any vehicle from a passenger car to an off-highway bulldozer with quality performance.

Piston Compressor Variants : SD5H & SD7H

Sanden compressors – Model SD5H09

Image of Sanden compressors - SD5H09 Image of Sanden compressors - SD5H09

Performance Curve

Compressor Specification :

Bore ø35
Stroke 18.07 mm
Displacement Per Revolution 87 cc/rev
Number of Cylinders 5
Max. Allowable Continuous Speed 6000 RPM
Max. Downshift Speed 7000 RPM
Refrigerant HFC134A
Oil (SP-20 or Equiv) 100 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD5H11

Image of Sanden compressors - SD5H11 Image of Sanden compressors - SD5H11

Performance Curve

Compressor Specification :

Bore ø35
Stroke 22.6 mm
Displacement Per Revolution 108 cc/rev
Number of Cylinders 5
Max. Allowable Continuous Speed 6000 RPM
Max. Downshift Speed 7000 RPM
Refrigerant HFC134A
Oil (SP-20 or Equiv) 135 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD5H14

Image of Sanden compressors - SD5H14 Image of Sanden compressors - SD5H14

Performance Curve

Compressor Specification :

Bore ø35
Stroke 28.6 mm
Displacement Per Revolution 138 cc/rev
Number of Cylinders 5
Max. Allowable Continuous Speed 6000 RPM
Max. Downshift Speed 7000 RPM
Refrigerant HFC134A
Oil (SP-20 or Equiv) 175 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD7H13

Image of Sanden compressors - SD7H13 Image of Sanden compressors - SD7H13

Performance Curve

Compressor Specification :

Bore ø29.3
Stroke 27.4 mm
Displacement Per Revolution 129.2 cc/rev
Number of Cylinders 7
Max. Allowable Continuous Speed 6000 RPM
Max. Downshift Speed 7000 RPM
Refrigerant HFC134A
Oil (SP-10 or Equiv) 135 cc
Rotation (Clutch View) Clockwise



Sanden compressors – Model SD7H15

Image of Sanden compressors - SD7H15 Image of Sanden compressors - SD7H13

Performance Curve

Compressor Specification :

Bore ø29.3
Stroke 32.8 mm
Displacement Per Revolution 154.98 cc/rev
Number of Cylinders 7
Max. Allowable Continuous Speed 6000 RPM
Max. Downshift Speed 7000 RPM
Refrigerant HFC134A
Oil (SP-10 or Equiv) 175 cc
Rotation (Clutch View) Clockwise

Rotary Scroll Compressors

This Compressor uses a unique design with two scrolls, one is fixed and the other is movable, both inter-locked. This gives continuous compression allowing operation at very high speeds, whilst maintaining a compact size and high volumetric efficiency

Rotary Compressor Variants : TRSA & TRSE

Sanden compressors – Model TRS

Image of Sanden compressors - TRSA & TRSE

TRSA05 Performance Curve

TRSA09 Performance Curve

TRSA12 Performance Curve

TRSE07 Performance Curve

TRSE09 Performance Curve

Variable Displacement Compressors

The Variable Capacity Piston Compressor (SDV) was developed to meet the current and future needs of car manufacturers. The compressor displacement is varied by changing the angle of the cam, which in turn controls the refrigeration capacity to meet air-conditioning demands at all operating conditions. Once cabin temperature approaches desired temperature, the Compressor can afford to reduce its capacity. This avoids clutch cycling and maintains a constant lower outlet temperature.

Variable Displacement Compressor Variants : SD6V & SD7V

Sanden compressors – Model SD6V

Image of Sanden compressors - SD6V

Performance Curve



Sanden compressors – Model SD7V

Image of Sanden compressors - SD7V

Flexible Compressors

Utilizing interchangeable parts, the FLX7 compressor series allows distributors to consolidate hundreds of unique part numbers into less than 20 which has increased customer satisfaction. The FLX7 doesn’t just replace existing models, it also creates compressor configurations previously unavailable from Sanden. Flexibility truly is the key benefit of this compressor series. The FLX7 can be adapted to satisfy a variety of applications. The two clutch lead wire options and six fittings are just the beginning. More options are in development and the result will be an even more adaptable and flexible FLX7 compressor series.

The FLX7 series is compatible with hundreds of different A/C systems. Each FLX7 comes standard with heavy duty clutch bearings, a clutch diode, and a pressure relief valve. The port fittings are low-profile and made from forged steel, giving them superior durability and lower weight to cast-iron fittings.

Sanden compressors – Model FLX7

Image of Sanden compressors - FLX7

  • Product Brochure FLX7
  • Pressure relief valve to guard against abnormal pressure conditions
  • Field Coil Diode to prevent electrical damage to the clutch
  • Heavy-duty clutch bearing to handle higher pressures and loads
  • Each FLX7 model has a pad style cylinder head ready to accept a forged steel port fitting
  • Forged-steel port fittings, each designed to fit the FLX7 cylinder head. This allows the end user to adapt a single compressor to fit a variety of applications

Enhanced SD7 Compressors

The Enhanced SD7 is a higher performance version of Sanden’s popular SD7H15 compressor. The improvements to the SD7H15 provide higher refrigerant gas flow, decreased gas re-expansion, and improved efficiency. The Enhanced SD7 has the same outer dimensions as the standard SD7H15, but is capable of 15% – 20% cooling capacity based on independent testing and  is ideal for applications that traditionally use 170cc – 210cc A/C compressors.

Since the Enhanced SD7 has the same mounting footprint as the standard SD7H15, no design engineering is required to make new mounting brackets. Simply utilize your existing mounting brackets.

The Enhanced SD7 is available in both ear mount and direct mount versions with a variety of clutch and porting configurations.

Sanden compressors – Model Enhanced SD7

Image of Sanden compressors - SD7 enhanced

Performance Curve

Applications Include :

  • Large AG or construction vehicles
  • Transport buses
  • School buses
  • Ambulances
  • Fire trucks
  • Motor homes
  • Military vehicles

Compressor Service Parts

Image of Sanden compressors - Service parts

Available Compressor repair and servicing parts :

  • Clutches & Coils
  • Cylinder Heads
  • Manifolds/Port Fittings
